Cable clamp type 2032 2205017

Cable clip – reliable cable fixing

The cable clip type 2032 is a practical and economical solution for fixing cables in electrical installations. Made of durable plastic, it provides stable support for the cables, minimizing the risk of their displacement and damage. The product is particularly useful during installation work inside buildings, both in newly built and modernized installations.

Features and application

The clip is designed for mounting NYM cables with a diameter of up to 8 conductors 3x1.5 mm². Its construction allows for easy installation without the need for additional tools. The mounting hole with a diameter of 6 mm allows the clip to be attached to various surfaces – walls, suspended ceilings or structural elements. The clamp height is 9 mm, and the spacer element is 13 mm. Made in gray color, the clip is discreet and blends well with the surroundings. The product is delivered in a raw state, which allows for possible additional modifications or painting.

Safety and compliance with standards

The cable clip 2032 is made of halogen-free material, which increases safety and limits the emission of toxic substances in the event of a fire. It does not have flame-retardant properties or meet the requirements for maintaining the functionality of E30/E90 systems during a fire. Nevertheless, it is a solid element of the electrical installation, ensuring safe cable routing. The material is a plastic with high mechanical and chemical resistance.
