Portable distribution box made of NYSA plastic, input: 2 m H07RN-F cable 5×4 with plug 32/5, output: 2×16/5, 3×GS, no protection, IP44 9030149W

Portable distribution board with CEE 32A plug and three type F sockets

The housing is made of plastic — probably PC/ABS, as indicated by its shock resistance and wide temperature range — and is resistant to mechanical damage, making the distribution board suitable for intensive use on construction sites. It operates safely in temperatures from -25°C to +40°C, without risk of material damage or loss of functionality.

Power is supplied via a fixed H07RN-F 5x4 cable 2 m long, terminated with a CEE 32A/5P plug. There is no CEE 32A socket on the panel — the device is not intended for connecting other distribution boards or higher‑power equipment through the same input. This limitation ensures that the load will not be incorrectly connected directly to the network inlet.

The panel features three type‑F sockets (CEE 7/3) with grounding — compatible with most standard European plugs. Additionally, two CEE 16A/5P sockets allow connection of tools up to 16 A, such as circular saws, grinding machines or pumps. All sockets are protected and rated for operation at 400 V.

The IP44 protection rating provides protection against water splashes and solid objects larger than 1 mm — allowing safe use in open areas, on damp surfaces, or in temporary conditions. It is not intended for operation under continuous rain or immersion.

It does not contain an internal overload protective device or a residual‑current device — the number of overload protectors is zero. Circuit protection must be provided by a device at the power source level, e.g., an overload breaker or a D0 fuse in a construction distribution board. This means the installer must ensure appropriate network‑level protection and cannot rely on built‑in protection in this distribution board.

Dimensions: 200 mm (height) × 197 mm (width) × 197 mm (depth). Color black — standard for industrial equipment.
