2-conductor lighting connector for push-buttons: from the luminaire side: for all types of conductors, from the installation side: for single-core wires, series 224, max. 2.5 mm², ambient temperature max. 60 °C, 2.50 mm, white. 224-112

Universal connection for lighting installations

The WAGO 224-112 connector is a reliable and quick solution for connecting wires in lighting installations. It allows you to connect solid core wires (from the installation side) with stranded, multi-strand or solid core wires (from the luminaire side) with a cross-section from 0.5 mm² to 2.5 mm². This makes it ideal for both new installations and renovations.

Quick installation and safety

The connector is designed with installers in mind. Installation is tool-free – simply press the wire into the appropriate clamp. CAGE CLAMP® spring clamp technology ensures a secure and durable connection, resistant to vibration and loosening over time. An additional measuring port facilitates voltage checking without the need to disassemble the connector. The use of reliable clamping technology adapted to the type of wires used guarantees safety.

Versatile application

The WAGO 224-112 connector finds application in many areas:

• Connecting luminaires (wall lights, chandeliers, spotlights).
• Chain connection of lighting points.
• Installations in residential and commercial buildings.
• Blind, roller shutter and awning drives.
• Control of electrical devices.

The connector is compatible with both copper and aluminum wires (when using Alu-Plus conductive paste). Made of high-quality materials, it ensures long-lasting and trouble-free operation even in difficult conditions. Thanks to its compact size, it is perfect for tight installation boxes.
