Thermal overload relay, EasyPact TVS, 7-10A, class 10A LRE14

Motor and Circuit Protection – EasyPact TVS Thermal Relay

This thermal relay, from the EasyPact TVS series, provides reliable protection for motors and electrical circuits against overload. Designed to work with fuse cartridges or GV2 L and GV3 L magnetic circuit breakers, it ensures effective protection in demanding working conditions. Its current setting range of 7-10A makes it ideal for use in motors up to 4 kW at 400V AC.

Mounting and Functionality

The LRE14 relay is characterized by simple direct mounting, which facilitates its integration with existing installations. It has a screw connection of the main contacts, providing secure and durable connections. It is equipped with one normally closed auxiliary contact and one normally open contact, allowing signaling of the operating status and remote control. Additionally, the presence of a reset button allows manual reset after the protection has activated. The lack of automatic reset increases system security – a reset requires operator intervention.

Safety and Compliance with Standards

In accordance with class 10 A tripping (IEC 60947-4-1), the relay responds to overloads as expected in typical industrial applications. The relay design provides protection against phase asymmetry and overload, minimizing the risk of damage and downtime. The product has European certification (IEC) and meets Green Premium requirements (RoHs/Reach), confirming its compliance with the latest environmental standards. This gives you the confidence that you are investing in a solution that is safe for people and the environment.
